Combination wrench set
Combination wrench set
OPEN BOX 13a
Artikel-Nr. 96404803|EAN 4018754080861
- Made in Germany - Combination spanner set in a sturdy roll-up case, 8 pcs.-pce., 7/16-7/8 mm, ring side 15° angled, DIN 3113 Form A / ISO 7738 Form A,
Produktvideo
Produkt-Varianten
| Product no. | Model no. | Number of tools | Weight | Capacy | |
|---|---|---|---|---|---|
| 96404803 | 13a/8 | 8 | 900 g | 7/16; 1/2; 9/16; 5/8; 11/16; 3/4; 13/16; 7/8 " | |
| 96404804 | 13a/20 | 20 | 3180 g | 1/4; 9/32; 5/16; 11/32; 3/8; 7/16; 1/2; 9/16; 19/32; 5/8; 11/16; 3/4; 25/32; 13/16; 7/8; 15/16; 1; 1 1/16; 1 1/8; 1 1/4 " | Jetzt entdecken |
| 96404812 | 13a/10KT | 10 | 750 g | 1/4; 5/16; 11/32; 3/8; 7/16; 1/2; 9/16; 5/8; 11/16; 3/4 " | Jetzt entdecken |
Technologien und Leistungsmerkmale
Double-T profile
Our combination and ring wrenches have an additional recess in the middle of the tool. Similar to the principle of a double-T beam, this provides a tremendous load capacity and maximum strength whilst reducing weight.
Thin-walled rings
The thin wall diameter of our rings makes it easier to work in confined spaces. The ring sides are taller than standard nuts, which prevents jamming.
Offset Shaft Design
Our wrenches are specially designed with additional reinforcement in the load zones where the greatest amount of force is transmitted - namely where the jaw meets the shank - in order to prevent deformation.
Eigenschaften
- Wrenches with metric, equal wrench sizes in roll-up pouch
- DIN 3113 Form A/ISO 7738 Form A
- jaw side straight, ring side 15° angled
- Sturdy, slim and lightweight intelligent construction
- High bending strength due to double T-profile
- STAHLWILLE round finish ensures a surface that is pleasant to the skin and has a good grip
- Extremely resilient, exceptionally durable
- drop forged, hardened and cooled in oil bath
- Chrome-Alloy-Steel, chrome plated
- Robust roll-up bag with hook-and-loop fastener made of polyester
- Mesh inserts allow a view of the inserted tool
- Safe protection of the tool with minimum space requirement
- Embroidered STAHLWILLE logo
Content:
SW 8; 10; 13; 16; 17; 18; 19; 22 mm
Produkt-Highlights
Non-slip surface.
STAHLWILLE wrenches have a high-quality surface finish with good grip, making it possible to work safely and efficiently, even with greasy hands. The non-slip property improves control during handling.
A solution for every situation.
Our combination wrenches are available in different versions (metric, imperial, long, with Spline-Drive profile) and as sets in textile bags, roll-up tool bags or TCS inserts.
