Torque wrench standard MANOSKOP® with fixed QuickRelease ratchet
Torque wrench standard MANOSKOP® with fixed QuickRelease ratchet
721QR/15 Quick
Artikel-Nr. 50204115|EAN 4018754268955
- Fast setting with easy-to-operate clamping lever in the handle, integrated lens for better readability of the set value
- Efficient. No reset to "0" necessary, as measuring element is only strained during the tightening process
- Ergonomically shaped, non-slip adjustment element with thumb recess and optimised ball handle for fatigue-free work
- Releasing torque wrench with permanently installed 1/2" QuickRelease ratchet, double stop signal (tactile and audible), left-hand tightening by turning over the plug-in tools
- With calibration certificate, display deviation ± 4%
Produkt-Varianten
| Product no. | Size | Measuring range N·m | Measuring range ft·lb | MA N·m | Nominal value N·m | External square drive (inch) | Length mm (L) | b1 | b2 | Height mm (h1) | Height mm (h2) | LF | Weight | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 50204115 | 15 | 30-150 N·m | 25-110 ft·lb | 30 N·m | 150 N·m | 1/2 | 452,5 mm | 28 mm | 41 mm | 23 mm | 18 mm | 387 mm | 1268 g | |
| 50204120 | 20 | 40-200 N·m | 30-145 ft·lb | 40 N·m | 200 N·m | 1/2 | 482 mm | 28 mm | 41 mm | 23 mm | 18 mm | 416,5 mm | 1338 g | Jetzt entdecken |
Technologien und Leistungsmerkmale
QuickRelease
The QuickRelease safety lock prevents unintentional loss of insert tools. These click securely into place, and are only released again at the push of a button for a quick tool change.
Factory calibration certificate (ISO calibration)
Our torque tools, transducers and test equipment are delivered with a factory calibration certificate in accordance with DIN EN ISO 6789-2 and based on DKD-R 10-8 for traceability of the measuring equipment.
2-component handle
Our 2-component handle is non-slip and ergonomically designed. It is resistant to the most common oils, greases, fuels, brake fluids and Skydrol. The arrow markings on the handle indicate the direction of operation.
Eigenschaften
- Triggering
- Flash adjustment by easy-to-operate clamping lever in the handle
- ergonomically shaped, non-slip adjustment element with thumb recess
- integrated magnifying glass in the reading window
- optimised ball handle for fatigue-free working
- double stop signal
- double scale N·m/ft·lb
- no resetting to "0" required, since the measuring element is only loaded during the tightening process
- Continued loading after release or loads in the opposite direction to the functional direction, e.g. in the case of stuck bolts.
- Continued load after triggering or loads against the functional direction, e.g. with stuck screws, do not act on the trigger mechanism, which is thus protected against damage.
- Protection of all sensitive parts by the robust steel tube housing
- Calibration with the perfectControl calibration device no. 7794 or the calibration system no. 7706. If necessary, readjustment without disassembly.
- Display deviation ± 4 %
- With certificate
Produkt-Highlights
Fast.
Rapid setting thanks to the easy-action locking lever in the handle. Ergonomically designed, non-slip adjuster with a thumb recess for fast, safe setting of the slider.
Adjustment does not require disassembly.
Quick adjustment from outside, no disassembly of the torque wrench required, with two adjustment points for the maximum & minimum values.
